Automotive Electronics PCBA Assembly Services
Automotive Electronics PCBA Technical Specifications
PCB Specifications
| Parameter | Specification |
|---|---|
| PCB Type | FR4 PCB / Aluminum PCB / Copper Core PCB / Ceramic PCB / Rigid-Flex PCB |
| Layer Count | 1–32 Layers |
| Board Thickness | 0.2–6.0 mm |
| Copper Thickness | 1–10 oz |
| Surface Finish | ENIG / Lead-Free HASL / OSP / Immersion Silver |
| Controlled Impedance | Supported |
| Lead-Free Process | RoHS Compliant |
SMT Assembly Capability
| Parameter | Capability |
|---|---|
| Assembly Technology | SMT / THT / Mixed Assembly |
| Minimum Component Size | 01005 |
| Fine Pitch IC | ≥0.30 mm |
| BGA / QFN / QFP Assembly | Supported |
| Placement Accuracy | ±0.03 mm |
| Double-Sided Assembly | Supported |
| Prototype & Mass Production | Supported |
Automotive Component Assembly
| Component | Capability |
|---|---|
| Automotive MCU | ✔ |
| Power MOSFET / IGBT | ✔ |
| CAN / LIN Interface IC | ✔ |
| Automotive Connectors | ✔ |
| Sensors | ✔ |
| Relays | ✔ |
| Power Modules | ✔ |
| LED Drivers | ✔ |
| DC-DC Converters | ✔ |
SMT Manufacturing Capability
Our automated SMT factory is equipped for high-mix, low-volume production as well as large-scale manufacturing.
Capabilities include:
- Automatic Solder Paste Printing
- High-Speed Pick & Place
- SPI (Solder Paste Inspection)
- AOI (Automated Optical Inspection)
- Nitrogen Reflow Soldering
- Wave & Selective Soldering
- X-Ray Inspection for BGA Components
- Flying Probe & Electrical Testing
Quality Control
Incoming Quality Control (IQC)
Every batch of components undergoes strict inspection before production.
Inspection items include:
- Approved Supplier Verification
- Component Authenticity Check
- Date Code & Lot Verification
- Moisture Sensitive Device (MSD) Control
- ESD Protection
In-Process Quality Control (IPQC)
Every production stage is monitored to ensure consistent assembly quality.
Process controls include:
- SPI Inspection
- AOI Inspection
- First Article Inspection (FAI)
- Reflow Profile Verification
- Process Parameter Monitoring
Functional Testing
Depending on project requirements, available tests include:
- ICT (In-Circuit Test)
- Functional Test (FCT)
- CAN/LIN Communication Test
- Power-On Test
- Voltage & Current Verification
- Signal Integrity Test
- Burn-In Test
- Aging Test
Final Quality Inspection
Before shipment, each assembly undergoes:
- Visual Inspection
- Electrical Verification
- Functional Testing
- Barcode & Batch Traceability
- Packaging Inspection
Manufacturing Standards
| Standard | Compliance |
|---|---|
| IPC-A-610 | Class 2 / Class 3 |
| IPC J-STD-001 | ✔ |
| ISO 9001 | ✔ |
| RoHS | ✔ |
| REACH | ✔ |
| Lead-Free Assembly | ✔ |
Automotive Electronics Applications
- Battery Management Systems (BMS)
- Electric Vehicle (EV) Electronics
- Automotive Lighting Control
- Body Control Modules (BCM)
- Engine Control Modules (ECM)
- Motor Controllers
- Charging Systems
- Dashboard & Instrument Clusters
- Infotainment Systems
- ADAS Support Modules
- Power Distribution Units
- Automotive Sensors
Why Choose Elidar
- Advanced High-Speed SMT Manufacturing
- One-Stop PCB Fabrication & Assembly
- Professional DFM & Process Engineering
- Reliable Global Component Sourcing
- Strict IQC, IPQC & OQC Quality Management
- Complete Traceability Throughout Production
- Prototype to Mass Production Support
- Stable Delivery and Responsive Technical Support
FAQ
Can you manufacture automotive-grade PCB assemblies?
Yes. We manufacture automotive electronics PCBAs according to customer specifications, following strict process controls, inspection procedures, and traceability requirements.
Do you support prototype and volume production?
Yes. We provide rapid prototyping, pilot production, and high-volume SMT manufacturing for automotive electronics projects.
What testing services do you provide?
We offer AOI, SPI, X-ray inspection, ICT, functional testing (FCT), burn-in testing, electrical testing, and customized verification based on customer requirements.
Can you source automotive electronic components?
Yes. We provide component sourcing through qualified supply channels and can work with customer-specified BOMs and approved vendor lists.
